Product Description
Galaxy & Ranger OEM Power Amplifier Heatsink Casting — DX-48T, DX-94HP, DX-95T (Part # MT2970064AR / RCI-6300F150)
Ensure proper thermal dissipation and structural mounting integrity for your high-output RF output transistors with this genuine OEM Galaxy / Ranger Power Amplifier Heatsink Casting (Factory Part Numbers MT2970064AR / RCI-6300F150). Machined to exact factory extrusion dimensions with pre-tapped transistor mounting pads, this heavy-duty aluminum heatsink provides the critical thermal mass required to prevent thermal runaway and premature transistor failure on high-wattage mobile chassis including the Galaxy DX-48T, Galaxy DX-94HP, Galaxy DX-95T, and compatible Ranger / RCI platform designs.
⚠️ THERMAL COMPOUND, MICA INSULATOR & NO-RETURN POLICY WARNINGS
• Thermal Compound & Mica Insulators Required: Always apply a thin, even layer of heat sink compound (thermal paste) and use proper electrical insulating mica/silicone washers between power transistors and the aluminum casting to prevent short circuits and ensure efficient heat transfer.
• Torque & Mounting Alignment: Ensure all transistor mounting screws are torqued evenly to avoid cracking transistor flanges or creating air gaps that trap heat.
• No-Return Policy Notice: Due to raw aluminum machining, custom thermal paste application, and semiconductor mounting requirements, replacement heatsink castings are strictly non-returnable once installed, modified, or thermal compound has been applied.
Product Specifications & Technical Data
- Manufacturer / Brand: Galaxy / Ranger / RCI (Genuine Factory OEM Service Replacement Part)
- Factory Part Numbers / SKUs: MT2970064AR, RCI-6300F150
- Material & Construction: Extruded Black-Anodized Aluminum Thermal Heatsink Casting with Precision-Machined Mounting Surface
- Component Designation: RF Power Amplifier Heatsink Assembly / Mounting Extrusion
- Dissipates thermal energy generated by final and driver RF power transistors/MOSFETs during high-power AM/SSB transmission
- Mounting & Fitment: Direct Factory Chassis Heatsink Replacement for Galaxy DX-48T, DX-94HP, DX-95T, and compatible RCI amplifier bays
- Quality Standard: 100% Genuine Factory Original Equipment Manufacturer (OEM) Electronic Component
- Compatible Radio Models:
- Galaxy High-Power Mobile Transceivers: Galaxy DX-48T, DX-94HP, DX-95T (and compatible high-wattage amplifier-equipped chassis)
- Ranger / RCI Transceivers: Select Ranger and RCI mobile chassis utilizing part numbers MT2970064AR or RCI-6300F150
Installation & Bench Notes
- Diagnoses & Solves: Warped, cracked, or stripped heatsink castings, chronic overheating during extended transmissions, and physical chassis damage.
- BENCH INSTALLATION PROCEDURE:
- Disconnect the 13.8V DC power cord and antenna coaxial cable. Remove top and bottom cabinet covers and extract the complete RF amplifier board/heatsink assembly from the main chassis.
- Carefully desolder or unbolt power transistors, thermal switches, and associated wiring attached to the old heatsink, keeping track of insulating mica washers and mounting hardware.
- Clean all old, dried thermal compound off transistor mounting tabs and inspect the new MT2970064AR / RCI-6300F150 heatsink mounting surface.
- Apply a fresh, thin layer of thermal paste to the transistor mating surfaces, ensuring clean mica/silicone insulators are correctly positioned between transistor tabs and the grounded aluminum heatsink.
- Bolt the transistors and circuit board securely to the new heatsink casting, torque evenly, and check for electrical isolation (continuity check between transistor collector/drain tabs and chassis ground to verify no accidental shorts).
- Reinstall the assembled heatsink back into the radio chassis, reconnect all wiring, and test thermal stability under load on the bench.
