Product Description
IC090 Voltage Controlled Oscillator (VCO) PCB Module
Resolve frequency lock issues and restore stable channel synthesis with this genuine IC090 VCO PCB Sub-Assembly Board. Designed as a drop-in replacement module for specialized CB and 10-meter radio mainboards, this factory pre-tuned oscillator board generates precise local oscillator signals required for clear transmit and receive phase-locked loop (PLL) operation.
Product Specifications & Features
- Component Type: Voltage Controlled Oscillator (VCO) PCB Sub-Module
- Designation / Part Number: IC090
- Condition: Brand New Factory Replacement Part
- Circuit Integration: Complete shielded oscillator daughterboard with coil, varactor circuitry, and pin headers
- Compatibility: Galaxy, Ranger, and RCI radio chassis utilizing the IC090 VCO circuit architecture
Key Benefits
- Fixes common VCO unlock symptoms, unreadable frequency counter displays, and lost RF transmit/receive.
- Pre-assembled daughterboard design eliminates the need to rebuild delicate oscillator tank circuits from scratch.
- Saves bench troubleshooting time by replacing the entire potted or prone-to-drift VCO sub-circuit at once.
